Cole-Parmer Masterflex L/S 07528-20 Peristaltic Pump

The Cole-Parmer Masterflex L/S 07528-20 peristaltic pump is a digital, variable-speed pump (drive) specifically designed for precision metering and transfer applications in laboratories, with a maximum speed of 300 RPM.

Specifications

Drive: Digital variable speed

Speed ​​range: 3–300 RPM

Speed ​​control: ±0.25% accuracy (at 300 RPM)

Flow range: 0.18 to 1700 mL/min (depending on pump head and tubing size)

Motor: Brushless, maintenance-free 1/10 hp motor (75 W)

Compatibility: Pump head accepts up to two Masterflex L/S pump heads (Standard, Easy-Load, High Performance, etc.)

Controls: Front panel with touch keys (membrane keypad), digital LED display, reversible motor

Connectivity: Remote I/O (remote input/output) via DB9 connector for start/stop, direction, and speed control (0-10 VDC or 4-20 mA)

IP rating: IP33 (splashproof)

Dimensions: (L x W x D) H) 274 x 211 x 216 mm

Power supply: 90 to 260 VAC, 50/60 Hz

Weight: 6.6 kg
