BioMérieux EMAG Nucleic Acid Extraction System

EMAG is a fully automated extraction platform for total nucleic acid purification from various clinical samples. With minimal hands-on time and a single standardized workflow, EMAG helps maximize laboratory productivity.

2 independent sections of 24 samples each
1 set of reagents and 1 unique disposable design
Various input/output tubes and compatibility with many matrices

Dimensions (HxWxD): 1810 x 1420 x 800 mm
Weight: 330 Kg
Sample Number: 1 to 48 reactions per run
Sample Volume: 10µl to 1000µl per sample
Elution Volume: 25µl to 200µl (5µl increment)
Run Time: Average of 98 minutes for 48 samples
LIS Connectivity: Yes
UV Lamp: Yes
HEPA Filter: Yes
IVD Compliance: CE marked according to IVD regulation 2017/746

Including PC and 1000 µL pipette tips and waste bags.
