Luminex 100 Flow Cytometry System

The Luminex 100 System is a flexible analyzer based on the principles of flow cytometry that enables you to multiplex (simultaneously measure) up to 100 analytes in a single microplate well, using very small samples. The system delivers fast and cost-effective bioassay results on many assay formats including nucleic acid assays, receptor-ligand assays, immunoassays, and enzymatic assays.

The Luminex 100 System is the combination of three core xMAP Technologies. The first is xMAP microspheres, a family of fluorescently dyed micron-sized polystyrene microspheres that act as both the identifier and the solid surface to build the assay. The second is a flow cytometry-based instrument, the Luminex 100 analyzer, which integrates key xMAP detection components, such as lasers, optics, fluidics, and high-speed digital signal processors. The third component is the xPONENT Software, which is designed for protocol-based data acquisition with robust data regression analysis.

Flow cytometry platform with lasers, APDs, PMTs
Multiplexing: Up to 100 analytes per sample (80 on MagPlex microspheres)
Dynamic Range (Typical): ≥3.5 logs
Read Time: 96-well plate in ≤45 min (up to 12,800 tests/hour)
Daily Start-Up/Shut-Down: ≤30 min
Sensitivity: 0.061 pg/mL (immunoassays)
Dimensions (WxHxD): 425 x 320 x 595 mm
Weight: 49 kg

Including PC
