Cole-Parmer MasterFlex L/S Peristaltic Pump

Speed range: 0.1 to 600 rpm

Dimensions (LxWxH): 267 x 203 x 203 mm

Weight: 5.9 kg

Equipped with a 77201-62 Easy Load II pump head

Tubing size: 15, 24, 35, 36

Tubing 15

Flow rate: 1.7 ml/min at 1 rpm, 1000 ml/min at 600 rpm

Discharge pressure: 1.7 bar (continuous), 2.7 bar (intermittent)

Vacuum: 26 Hg at 600 rpm

Suction lift: 8.8 m at 600 rpm (H₂O)

Tubing 24

Flow rate: 2.8 ml/min at 1 rpm, 1700 ml/min at 600 rpm

Discharge pressure: 1.7 bar (continuous), 2.7 bar (intermittent)

Vacuum: 26 Hg at 600 rpm

Suction lift: 8.8 m at 600 rpm (H₂O)

Tubing 35

Flow rate: 3.8 ml/min at 1 rpm, 2300 ml/min at 600 rpm

Discharge pressure: 1.4 bar (continuous), 2.4 bar (intermittent)

Vacuum: 26 Hg at 600 rpm

Suction lift: 8.8 m at 600 rpm (H₂O)

Tubing 36

Flow rate: 4.8 ml/min at 1 rpm, 2900 ml/min at 600 rpm

Discharge pressure: 1.0 bar (continuous), 1.4 bar (intermittent)

Vacuum: 24 Hg at 600 rpm

Suction lift: 8.3 m at 600 rpm (H₂O)
