CAB Mach4/600B Labelprinter

The MACH4 label printer is one of the leading label printing solutions thanks to its exceptional performance and high-quality print.

This line of label printers offers all the features of a high-class industrial printer with a wide range of applications at an attractive price. The printing mechanism is made of the finest materials and perfectly harmonizes form and function.

Printer technology: Label printer, Thermal transfer / Direct Thermal

Print resolution: 600 dpi

Maximum print speed: 100 mm/s

Maximum print width: 105.6 mm

Maximum media width: 120 mm

Maximum label height: 2000 mm

Label roll (outside diameter): maximum 210 mm

Label roll (core inside diameter): 38.1 – 76 mm

Label winding direction: Inner or outer wound

Core ribbon size: 25 mm inner core diameter

Ribbon length: 360 m

Ribbon size (outside diameter): 72 mm outer diameter

Ribbon width: 114 mm
Standard interfaces: Serial RS232, USB 2.0 High Speed ​​Slave for PC connection, Ethernet 10/100 Base T, LPD, RawIP printing, DHCP, HTTP, FTP, SMTP, SNMP, Time client; Peripheral connection; USB Master for keyboard and scanner.

Standard fonts: 5 Bitmap fonts including OCR-A, OCR-B, and 3 Vector fonts (Swiss 721, Swiss 721 Bold, and Monospace 821) available internally, loadable TrueType fonts. Character sets: Windows 1250 to 1257, DOS 437, 737, 775, 850, 852, 857, 862, 864, 866, 869, EBCDIC 500, ISO 8859-1 to -10 and -13 to -16, WinOEM 720, UTF-8, Macintosh Roman, DEC MCS, K0I8-R. all West and East European Latin, Cyrillic, Greek, Hebrew and Arabic characters.

Graphics: Lines, arrows, frames, circles

Images: PCX, IMG, BMP, TIF, MAC, GIF, PNG

Linear barcodes: Code 39, Code 93, Code 128 A B C, Codabar, EAN 8-13, EAN/UCC 128, FIM, HIBC, Int 2/5, Ident and Lead Code, JAN 8-13, MSI, Plessey, Postnet, RSS14, UPC A, E, EO

2-Dimensional barcodes: Aztec, Codablock F, Data Matrix, PDF 417, Micro PDF 417, UPS Maxicode, QR Code, RSS 14

Dimensions (WxHxD): 240 x 290 x 425 mm

Weight: 9 kg

Software not included
