IKA RCT Basic Safety Control Heating plate with magnetic stirrer

The IKA RCT basic safety control is a high-quality laboratory heating plate with an integrated magnetic stirrer, designed for the simultaneous heating and homogeneous mixing of liquids up to approximately 20 liters. The device is known for its precise temperature control, powerful stirring motor, and extensive safety features, including an adjustable safety temperature, “Hot Top” warning, and dual temperature monitoring, making it highly suitable for both routine and unattended use in laboratories.

🔬 Technical specifications

Feature Specification

Type Heating plate with magnetic stirrer

Max. Stirring volume (H₂O) 20 liters

Speed ​​range 50 – 1500 rpm

Speed ​​accuracy ± 10 rpm

Plate temperature range up to approx. 310 °C

Adjustable safety circuit 50 – 360 °C

Heating power approx. 600 W

Power consumption approx. 650 W

Heating speed approx. 6.5 K/min

Plate dimensions Ø 135 mm

Plate material Aluminum alloy (polished)

Display Digital (temperature & speed)

Temperature sensor PT1000 (external possible)

Protection class IP42

Dimensions (W×H×D) approx. 160 × 85 × 270 mm

Weight approx. 2.5 kg

Power supply 100–230 V, 50/60 Hz
