IKA Plate (RCT digital) Magnetic Stirrer with Heating

IKA Plate (RCT digital) Magnetic Stirrer with Heating

The IKA Plate (RCT digital) is a high-quality magnetic stirrer with an integrated heating function, designed for accurate and reproducible laboratory applications. Thanks to the robust aluminum alloy heating plate and powerful magnetic drive, the device is suitable for stirring liquids up to 20 liters (H₂O) at a speed of 50 to 1,500 rpm.

The IKA Plate (RCT digital) distinguishes itself through its modern design, intuitive operation, and advanced technology. Furthermore, IKA offers a lifetime warranty on the magnetic stirrer drive, a unique advantage within the laboratory industry. Regular firmware updates ensure that the device meets the latest functionalities and performance standards in the future.

The integrated IKA SmartTemp function increases safety by preventing overheating, while the built-in timer and counting functions are ideal for monitoring kinetic processes and temperature-sensitive reactions. The included PT 1000.60 temperature sensor enables highly accurate temperature control of the sample. Key features

Magnetic stirrer with integrated heating plate

Maximum stirring capacity: 20 liters (H₂O)

Speed: 50 – 1,500 rpm

Aluminum alloy heating plate for optimal heat transfer

Precise temperature control with PT 1000.60 temperature sensor

Integrated IKA SmartTemp safety function

Timer and counting function

Firmware updates via USB

Lifetime warranty on the magnetic drive

Robust and chemically resistant design

Technical specifications

Type: Magnetic stirrer with heating

Max. stirring volume (H₂O): 20 liters

Speed ​​range: 50 – 1,500 rpm

Speed ​​setting resolution: 10 rpm

Max. heating power: 600 W

Heating temperature: Up to 310 °C

Max. medium temperature: Approx. 310 °C (with external sensor)

Temperature setting 1 °C increments

Control type Electronic

Temperature sensor connection PT 1000.60

Display Digital TFT display

Timer Yes

USB interface Yes

Protection class IP42

Power supply 220–240 V, 50/60 Hz

Width: 150 mm x Depth: 270 mm x Height: 105 mm

Heating plate dimensions: Ø 135 mm

Weight: approx. 2.7 kg
