Applikon My-Control Fermentation Controller

The Applikon my-Control fermentation controller from Getinge Applikon is an advanced and compact bioprocess controller, specifically developed for small-scale fermentation and cell culture processes. The system is suitable for both microbial and cellular applications and can control bioreactors with a working volume of approximately 50 ml to 3 liters.

Thanks to the integrated web interface, the my-Control is easy to operate via PC, tablet, or smartphone. The system offers full control over all critical process parameters such as pH, temperature, dissolved oxygen (DO), stirring, foaming, and level, and supports advanced control strategies such as autotuning PID control.

The controller is ideal for applications such as screening, medium optimization, process development, and scaling up, where accurate and reproducible results are essential. 🛠️ Technical specifications
Function Specification
Model Applikon my-Control
Application Fermentation / bioreactor control
Bioreactor operating volume approx. 50 ml – 3 l
Suitable for microbial and cellular cultures
Control: Web-based interface (PC, tablet, smartphone)
Control technology: Adaptive PID control with automatic tuning
Temperature range: 0 – 150 °C (Pt-100 sensor)
Stirring speed: 0 – 2000 rpm
Gas control: Up to 4 mass flow controllers (MFC)
Liquid dosing: Up to 4 variable pumps (±40 ml/min)
Sensors: pH, dissolved oxygen, redox, temperature, foam/level
Additional sensors (optional): Biomass, exhaust gas, balance
I/O capabilities: Up to 4 analog inputs/outputs, 8 digital outputs
Power supply: 100–240 V, 50/60 Hz (~400 VA)

Dimensions (approx.): ±19 × 35 cm (compact tabletop model)
Certification: CE, GAMP, 21 CFR Part Complies with Standard 11

This unit was specifically purchased for a pilot project aimed at the production of xylitol from xylan. Unfortunately, the project was cancelled before it was put into operation, meaning this controller was never used, commissioned, or connected to a vessel by us.

Includes manual and license key
This is essentially a brand-new unit at a discount. Ideal for biofuel research, food science, or biochemical research (including yeast or bacterial fermentation).
