GE Healthcare Cytiva Rocker, Tray 20 and Lid 20 for Xuri W25 System

Rocker specifications

Rocking speed control range: 2 to 40 rpm

Rocking angle control range: 2° to 12°

Rocking speed profile range: 15% to 100% (The % value refers to the fraction of the angular displacement function that is sinusoidally shaped 15% gives an almost constant angular velocity 100% gives a sinusoidal rocking)

Media weight control range: 0.5 to 25 kg

Scale, absolute accuracy (single mode): ±(0.050 + 1% of load) kg

Scale, left/right absolute accuracy (dual mode): ±(0.1 + 6% of load) kg

Temperature sensor: Pt100 Class A

Temperature measurement range: 2°C to 50°C

Temperature setpoint difference (dual mode): Max 10°C at ambient 21°C (The setpoint difference is reduced by 1°C for every degree centigrade that is increased from ambient temperature (e.g., at ambient 25°C, max setpoint difference is 6°C))

Temperature control range: (Ambient temperature + 5°C) to 40°C

Temperature control accuracy (excl. measurement error): ±0.2°C

Dimensions rocker (WxHxD): 404 x 205 x 560 mm

Weight rocker: 24 kg

Excluding software
