Optics: Infinity-corrected optical system, RMS threaded targets with 45 mm parfocal distance

Objectives: LPlan PH2 10x/0.25 – LPlan PH2 4x/0.13 – LPlan PH2 20x/0.40

Illumination: LED with adjustable intensity (>50,000 hours lifespan per light module)

Contrast methods: Transmitted light (brightfield and phase contrast)

Revolver: 4-position, manual operation

Condenser: 3-position revolver for brightfield and phase contrast

Condenser working distance: 60 mm

Table: Fixed table

Focusing mechanism: Coaxial focusing knobs with tension control

Coarse focus: 38 mm/revolution

Fine focus: 0.2 mm/revolution, precision 0.002 mm

LCD screen: 12.1-inch high-resolution color monitor (1024 x 768 pixels) with adjustable tilt

Camera: Color camera, 1/2 inch, 2048 x 1536 pixels, 3.1 megapixels

Image capture: Built-in operating system with software for image capture and storage via mouse or manual buttons on the front

Stored images: Color camera; 24-bit full color; TIFF, PNG, JPEG, BMP; 2048 x 1536 pixels

Output ports: Two USB 2.0 ports

Power supply: AC adapter; input 100-240 V, 47-63 Hz; output 12 VDC / 2.0 A, max. 24 W

Dimensions: 40.6 x 31.8 x 53.3 cm

Weight: 9.1 kg
