Siemens IMMULITE 1000 Immunoassay System

The IMMULITE 1000 is an immunoassay system used for measuring immunological parameters in clinical laboratories. The system uses chemiluminescence technology and offers an extensive assay menu, with more than 75 assays, and a high throughput of 120 tests per hour.

Assays

Allergy:

AlaTOP Allergy Screen

ECP

IgE Total

Anemia:

EPO

Ferritin

Vitamin B12

Bone Metabolism:

Intact PTH

Osteocalcin

Pyrilinks-D

Cardiac:

CKMB

D‐Dimer

High‐sensitivity CRP

Myoglobin

NT‐proBNP

Troponin

Diabetes:

Albumin

C-Peptide

Insulin

Growth:

Growth Hormone (hGH)

IGF-1

Inflammation:

IL‐1B

IL‐10

IL‐2R

IL6

IL8

LBP

TNF‐α

Metabolic:

ACTH

Cortisol

Homocysteine

Oncology:

AFP

CA 125 (OM-MA)

CA 15-3 (BR-MA)

CA 19-9 (GI-MA)

Calcitonin

CEA

Free PSA

PAP

PSA

PSA, 3rd Generation

Other:

ß2-Microglobulin

Gastrin

Nicotine Metabolites

Reproductive Endocrinology:

Androstenedione

DHEA-SO4

Estradiol

Free Beta HCG

FSH

hCG

LH

PAPP-A

Progesterone

Prolactin

SHBG

Testosterone

Unconjugated Estriol

Special ID:

H. pylori IgG

Therapeutic Drug Monitoring (TDM):

Carbamazepine

Digitorin

Digitoxin

Phenobarbital

Phenytoin

Theophylline

Valproic Acid

Thyroid:

Anti-Tg Ab

Anti-TPO

Free T3

Free T4

Thyroglobulin (Tg)

Thyroid Binding Globulin (TBG)

Total T3

Total T4

TSH

TSH, 3rd Generation

T Uptake

ToRCH:

CMV IgG

CMV IgM

Herpes I & II IgG

Rubella IgG

Rubella IgM

Toxoplasma IgG

Toxoplasma IgM

Veterinary:

Canine Total T4

Canine TSH

Canine FT4

Vet Cortisol

Vet Free T4

System Description: Random access immunoassay system

Throughput: Up to 120 test per hour in random or batch access mode

Time To First Result: 42 minutes standard mode, 15 minutes turbo mode

Assays On Board: Up to 12

Sample Types: Serum, plasma

Sample Tubes: Indirect tube sampling

Sample and Reagent integrity control: Liquid level sensors

Barcodes Formats Supported: Code 38, Code 128, Codabar, and I-2 of 5 (Interleaved)

Reagent Positions: 12

Reagent Barcodes: Allows operator to auto load calibration information and test parameters.

Dimensions (HxWxD): 480 x 1170 x 660 mm

Weight: 109 kg
