Millipore Elix 100 Water Purification System ncluding 350L storage tank with automatic UV sanitation module
Roll over image to zoom in
Click to open expanded view
Elix systems have been designed to deliver the highest pure water quality for your regular laboratory applications and instrument feed. Elix is suited to every user’s needs in today’s demanding laboratory environment. Elix water quality is ideal for the preparation of reagents and buffers, for microbiology media, hydroponics or histology. It is also the best feed for all Milli-Q and Super-Q ultrapure water systems, as well as instruments such as glassware washers, autoclaves and hydrogen generators.
Superior and consistent Type 2 water quality – “Superior”, as resin beads are not degraded by exposure to harsh regeneration chemicals. “Consistent”, as the continuous regeneration avoids the drawbacks of quality variations from resin exhaustion.
Cost & labor savings – Elix module contains special carbon beads at its cathode therefore, does not require water softening. Its self-regeneration technology avoids the hassle and costs around DI cartridge replacement. Elix is “green” consuming low energy with a small carbon footprint.
Long lasting technology – thanks to its proven design, the module continuously regenerates its resin beads without the need for any maintenance.
Elix pure water is irradiated by a bactericidal UV lamp before entering the storage tank. The reservoir design maintains consistent purity of stored water. The vent filter provides effective protection against airborne contaminants and the ASM, Automatic Sanitization Module, prevents biofilm formation. Elix water can then be sent by a distribution pump to feed instruments or a distribution loop. They can be integrated into a centralized system, providing total control of all parameters within the system itself as well as within the external pure water distribution loop.
Resistivity at 25 °C: > 5 MΩ•cm
TOC: < 30 ppb
Bacteria: < 10 CFU/mL
Silicate removal: > 99.9 %
Production flow Rate: 100 L/h
Water quality: Potable tap water
Feed water conductivity at 25 °C: < 2000 µS/cm
Feed water pressure: 2 – 6 bar
Feed water temperature: 5 – 35°C
Feed water chlorine: Application Specialist will determine pretreatment required
Feed water fouling index: Application Specialist will determine pretreatment required
Feed water pH: 4 – 10 pH units
Feed water connection: ½ in Gaz M
Dimensions (H x W x D): 734 x 662 x 441 mm
Operating weight: 45 – 62 kg
Data port connection: RS232
Including 350L storage tank with automatic Uv sanitation module.
Excl. new filters
Used, in good condition
