Electro-mechanical lid lock system
Dual interlock mechanism
Air removal time setting
Effective capacity: 50 L
Chamber size (Ø x H): 300 x 710 mm
Operation mode: 4 modes (LIQUID with warming, LIQUID without warming, SOLID, DISSOLUTION), one memory for each mode
Temperature setting range sterilization: 105°C – 126°C (Variable)
Temperature setting range dissolution: 60°C – 100°C (Variable)
Temperature setting range warming: 45°C – 60°C (Variable)
Time setting range sterilization: 1 min – 250 min, Remaining time is displayed
Time setting range dissolution: 1 min – 60 min, Remaining time is displayed
Time setting range warming: 20 h (fixed)
Time setting range auto-start timer: Program autoclave to start 1 min to 1 week later
Exhaust setting: 4 levels from 0 to 3 (Variable), In SOLID mode, it is fixed to level 3 (forced cooling)
Exhaust setting: 0% – 100%, Valve opening degree setting for LIQUID mode
Maximum working pressure: 0.26 MPa
Thermometer: 5°C – 137°C
Pressure gauge: 0 MPa – 0.4 MPa
Alarms, error display: Low water heating, Temperature sensor wire disconnection, Over-temperature, Over-cool, Over-pressure, Abnormality in lid opening / closing lever lock
Dimensions (WxDxH): 547 x 532 x 1045 mm
Weight: 57 kg
| Weight | 0,0 kg |
|---|---|
| Warranty | 6 months |
| Condition | Used, in good condition |
| Date of Manufacture | 2012 |
| Brand | Other brands |
